RHINOCUT PRO CNC ROUTER MACHINE

- HGR20 rails with HGR20CA Bearing Blocks. - 1.25mod Helical Tooth Rack Gear with Pinion Gearbox : Dual On Y Axis and Single On X Axis - SFU1605 500mm Ball Screw on Z axis. - 3kW Air cooled VFD spindle 10-24000RPM ,ER20 ,Collets included: 2mm, 3mm, 4mm, 6mm ,8mm - Nema 23x112mm - 2.8Nm Stepper Motors on Z Axis - Nema 34x151mm - 12Nm Stepper Motors - Dual Y axis ,Single X Axis. - 50mm x 50mm Steel base frame with dual 76mm x 50mm steel gantry. - 8mm Mild steel plates. -DDCS V4.1 3 Axis Offline Controller with MPG. - 220v Max. Recommended 60A Circuit Breaker. - Startup Bit Set Included : Double Flute End Mill Cutting Bits - 3.175mm, 6mm Single Flute End Mill Cutting Bits - 3.175mm, 6mm 1 Hour Machine Oppertion Training ONLY included - no CAD/CAM training included
